Adopting the Delta-sigma analog-to-digital conversion and digital filter processing technology. It is very easy to build a master/slave controlling system via RS232/485serial port 、IO with PLC host devices.
Technical parameters
|
Division |
100000 |
|
Display |
Dual line VFD display |
|
AD converter |
Σ/Δ24 bit AD converter, analog and digtal fitering AD sampling rate：400HZ |
|
Calibration And function |
Calibration ：weight-free&weight calibration Filter：Multistage dynamic digtal filter, zero-tracking |
|
Nonlinearity |
Better than 0.002%FS |
|
Load cell |
Excitation voltage：5VDC Number：6*350Ω Type：Four-wire or six-wire |
|
Communction |
RS232, RS485 |
|
installation |
Panel mount |
|
Operating temperature |
-10℃-40℃, non-condensing Housing material：Aluminum shell power：24VDC |
|
Options |
8IN12OUT |
Outline Dimension
Feature●7-digit VFD Main display, 14-digit VFD auxiliary display
●Multistage dynamic digital filter, meet the demand of high speed dynamic weighing
●Display weight、accumulative weight and package
●Resistance to electromagnetic interference、Shock resistant
●Support 1 RS232/485, 1 RS485 Serial communication,support MODBUS-RTU
●Support 1 loadcell port，up to 4 x 350 ohm load cells
●400HZ/200Hz /100Hz A/D updating rate
●Simple comparison control mode, Sequence control mode, sacking-clamping control with weighing bucket mode, sacking-clamping control without weighing bucket mode.
●Support peripherals, including remote screen
