Adopting the Delta-sigma analog-to-digital conversion and digital filter processing technology. It is very easy to build a master/slave controlling system via RS232/485serial port with PLC host devices.
Technical parameters
|
Division |
150000 |
|
Display |
LED display |
|
AD converter |
Σ/Δ24 bit AD converter, analog and digtal fitering |
|
Calibration And function |
Calibration ：weight-free&weight calibration Filter：Multistage dynamic digtal filter, zero-tracking |
|
Nonlinearity |
Better than 0.002%FS |
|
Load cell |
Excitation voltage：5VDC Number：6*350Ω Type：Four-wire or six-wire |
|
Communction |
RS232, RS485 |
|
installation |
Panel mount |
|
Operating temperature |
-10℃-40℃，non-condensing Housing material：Aluminum shell power：24VDC |
|
Options |
4IN6OUT |
Outline Dimension
Feature
●Support RS232/RS485 Serial communication
●Level 1 / level 2 / Level 3 /Level 4 AD updating speed
●Multistage dynamic digital filter, meet the demand of high speed dynamic weighing
●Resistance to electromagnetic interference、Shock resistant
